ABOU-C...(FM):Modularsurge arrester with integratedbackup device foruse in PV systems
High reliability due to "Thermo Dynamic Control"SPD monito -ring device
Multifunctional terminals for connecting conductors and busbars
| 10mm solid/flexibleTYPE | ABOU-C100 |
| SPD classification accordingto EN61643-11 | Type2 |
| SPD classification according to IEC61643-11 | Ciass I1 |
| Max.Continuous operating a.c.Voltage[Uc] | 385Vac |
| Nominal discharge current(8/20μs)[In] | 50kA |
| Max.discharge current(8/20μs)[lmax] | 100kA |
| Voltage protection level[Up][L,N→PE] | ≤2.5kV |
| Voltage protection level at 5kA[Up][L,N→PE] | ≤0.5kV |
| Response time [ta]. | 25ns |
| Max.mains-side overcurrent protection | 250A gL/gG |
| Operating temperature range[Tu] | -40℃~+80℃ |
| Operating statel/fault indication | Green/red |
| Cross-sectional area(min.) | 10mm solid/flexible |
| Cross-sectional area(max.) | 35mm²solid/25mm flexible |
| Formounting on | 35mmDIN rail acc.ToEN60715 |
| Enclosure material | PBT/PA66,UL94V0 |
| Place of installation | indoor |
| Degrees of protection by enclosure | Ip20.To IEC60529/EN 60529 |
| Approvals | IEC61643-11,EN61643-11,CE,CB,TUV |
| Switching capacity a.c. | 250V/3A |
We reserve the right to modify design,technology,dimensions,weights and materials according to technical progress.
Illustrations are non-binding.Pictures may differfrom the modules described.
