Fast heat dissipation with excellent thermal performance
Features trivalent chromate-plated zinc screws providing excellent rust resistancehigh stability, and superior salt spray corrosion performance.
Characteristics
Characteristics
| Type | ABRT05-A | ABRT08-A | |
Nominal load | Current | 10A 16A | |
| Voltage | 300V | ||
| Dielectric strength | Between coil and contact | 4000 V/min | |
| Between contacts | 2500 V/min | ||
| Max. tightening torque | 1.0Nm | ||
| Wire size | 20-14/0.5-2.5 AWG/mm2 | ||
| Ambient temperature | -40~+85°C | ||
| Unit weight | 22g | 27g | |
| Type | ABRT05-ES | ABRT08-ES | |
| Nominal load | Current | 10A 16A | |
| Voltage | 300V | ||
Dielectric strength | Between coil and contact | 4000 V/min | |
| Between contacts | 2500 V/min | ||
| Max. tightening torque | 1.0Nm | ||
| Wire size | 20-14/0.5-2.5 AWG/mm2 | ||
| Ambient temperature | -40~+85℃ | ||
| Unit weight | 22g | 27g | |
